Warmbrite 200 – Series 4
A stylish re-imagining of a traditional, medium-size, fan-forced convection wood fire engineered to effectively heat living spaces up to 200m2. Because of its minimum clearance requirements, the Warmbrite 200 is ideal for compact environments where space is limited. The Warmbrite 200 comes equipped with a 3-speed electric fan that allows you to move the hot air more evenly around the home when the fire is roaring, an 8mm Easyfit baffle plate and will accommodate logs up to 350mm in length to maintain a longer burn through-out the night.
KEY BENEFITS
- Efficiently heat up to 200m2
- Clearview air wash system reduces blackening of glass and cuts down cleaning and maintenance.
- Quality you can trust from Scandia with a 10 year firebox warranty
Reviews (0)
TECHNICAL DETAILS
- Heat up to 200m2
- Fan-forced convection heating
- 5.5mm heavy duty firebox
- 10 year firebox warranty
- Firebox: 500w x 360d x 300h
- Heater: 595w x 505d x 724h
- Outperforms Australian Standards
CLEARANCES
| Clearance to Combustible Surfaces (mm) | |||||
|---|---|---|---|---|---|
| A | B | C | D | ||
| 475 | 125 | 450 | 225 | ||
| Unit Dimensions (mm) | |||||
|---|---|---|---|---|---|
| WIDTH | HEIGHT | DEPTH | WEIGHT | ||
| 595 | 720 | 505 | 125 kg | ||
| Firebox Dimensions (mm) | |||||||
|---|---|---|---|---|---|---|---|
| WIDTH | HEIGHT | DEPTH | |||||
| 500 | 300 | 360 | |||||
The above clearances are applicable when using the Scandia Sleek Black flue fitted with an additional heat shield.
Above clearances are a guide only. Diagrams are not drawn to scale and are for illustrative purposes. Please refer to user manual for further information.
WARMBRITE VIDEO
WHAT YOU WILL NEED
FLUE KIT OPTIONS
Sleek Black Flue Kit 3171234
Black Mesh Flue Kit 3180672
ROOF FLASHING OPTIONS
Metal Roof Flashing 3171673
Tile Roof Flashing 3171672
HEARTH OPTIONS
Straight 1050mm x 1200mm
or Corner 1425mm x 1425mm
Please note: All wood fires must be installed by a qualified person whose work conforms with local council regulations, Australian/New Zealand standards (AS/NZS 2918:2018) & manufacturers recommendations.
